■ Product Introduction
The 20 Lane Capsule Pill Checkweigher is a high-precision online weighing device designed specifically for the pharmaceutical industry.200K pcs/h Pharma Weight Inspection Machines verifies that the weight of individual capsules meets standard requirements. Based on dynamic weighing principles, this device enables 100% inspection on high-speed production lines, effectively rejecting underweight, overweight, and empty capsules to ensure consistent dosage and quality compliance for each capsule.
■ Tech Specifications
Type:SG-JN20
Weighing scope:5-2000mg
Display scale:0.1mg
Highest sorting accuracy:±0.5mg
Product specification:Capsule-00#-5#/Wafer-Φ5.5-Φ18mm/Thickness-3-12mm/Pill-Φ5.5-Φ12mm(Other sizes or shapes subject to testing)
Highest sorting ability:200000 PCS/HR
Number of columns:10 Columns/20 Columns/30 Columns
Power supply:AC-220V±10%, 50HZ
Compressed air:0.3-0.9Mpa
Use environment:15~30°C (The temperature change during use should not exceed the range of 1°C/h.Humidity:30-70%(but no condensation)
Weight of Machine :500kg
Shell material:SUS304
■ Main Features
1. High-Precision Dynamic Weighing
Equipped with a high-precision electromagnetic force compensation sensor, this system achieves milligram-level dynamic weighing, ensuring accurate and reliable weight measurement for each capsule.
2. 100% Online Full Inspection
Enables capsule-by-capsule inspection on high-speed production lines, enabling real-time identification and rejection of empty, underweight, and overweight capsules, preventing unqualified products from reaching the next stage.
3. Multi-Channel Inspection System
Multi-column inspection modes can be flexibly configured to meet production needs, improving production efficiency.
4. Automatic Sorting and Rejection
Equipped with a high-speed pneumatic or electric rejector, this system accurately separates qualified and unqualified capsules, ensuring smooth and rapid rejection.
5. Data Statistics and Traceability
Automatically records test results, production statistics, and abnormality information, and can export test reports for quality tracking and production analysis.
6. Intelligent Control and Human-Machine Interface
The system utilizes an intuitive touchscreen operating system with support for English and Chinese language switching and multi-level permission management for easy operation.
7. Designed to meet pharmaceutical standards
The structure is constructed of 304 stainless steel and food-grade materials, ensuring dust and static resistance. The entire machine complies with GMP and FDA regulations.
8. Quick Cleaning and Maintenance
The modular design allows for quick assembly and disassembly of the conveyor belt and weighing platform, facilitating cleaning and routine maintenance.
■ Application
■ Customers
■ Exhibitions
■ Packaging & Delivery
● Our machines undergo comprehensive testing and commissioning before shipment to ensure stable and reliable performance.
● Equipment is packaged in thickened wooden crates with shock and moisture-proof interiors to effectively prevent damage during transportation.
● We partner with several professional international logistics companies and support a variety of shipping methods, including sea, air, and land transport.
● Ensure the equipment arrives safely and on time at your facility.
