|| Product Introduction
The Box Heavy Object Checkweigher is an online dynamic weighing device designed specifically for heavy, boxed, and full-case packaged products. It is suitable for weight inspection and quality control in the food, beverage, chemical, daily chemical, and manufacturing industries. Food Grade Checkweigher enables high-speed, accurate dynamic weighing during transport, ensuring that the net weight of each box of products meets standard requirements.
|| Tech Specifications
Type:SG-450
Weighing Range:1-20/30kg
Limited of product:L: 550 W:450 H: 3-400mm
Accuracy:±5/10g Depend on products
Division Scale:0.1g
Belt Speed:0-60 m/min
Max Speed:40 pcs/min
Belt Width:450mm
Power Supply:AC 110/220V ±10% 50HZ
Power:400W
Main Material:SU304 stainless steel
|| Main Features
1. Online Automatic Weighing Function:
Enables continuous dynamic weighing of entire boxes or heavy products without manual intervention, automatically detecting product weight during transport.
2. Automatic Overweight/Underweight Rejection:
The equipment automatically rejects boxes of overweight or underweight products according to a set standard weight range, ensuring that the net weight of each box is qualified.
3. High-Precision Dynamic Detection:
Employs high-performance weighing sensors and advanced digital filtering algorithms, maintaining stable and accurate weighing results even in high-speed transport or vibrating environments.
4. Strong Load-Bearing Structure Design:
The frame and conveyor system are reinforced to withstand boxed or drummed products weighing from 1 kg to 50 kg, ensuring stable and reliable operation.
5. Data Recording and Traceability:
The system features weighing data statistics, report generation, out-of-tolerance alarm recording, and production traceability functions. Data can be exported via USB or Ethernet for easy quality management.
6. Multiple Rejection Methods:
Depending on product characteristics, push-bar, baffle, lifting, or diversion rejection mechanisms can be selected to ensure accurate sorting of boxes of different weights and sizes.
7. Intelligent User Interface:
Equipped with a color touchscreen HMI interface supporting Chinese and English language display, it allows for quick setting of weighing parameters, viewing of operating status and historical records, and is easy to operate.
8.System Integration Function:
It can be integrated with automatic packaging lines, labeling machines, metal detectors, barcode scanning systems, etc., to build a complete automated inspection production line.
9. Alarm and Self-Check Functions:
The system automatically alarms when abnormal weight or equipment malfunction is detected; it also features self-check and automatic zero-point calibration functions to ensure stable operation.
10. Multi-product parameter storage:
Supports the storage and quick switching of multiple product formulas to meet the weighing requirements of different specifications of boxed products.
|| Application
|| Our Customers
|| Our Exhibitions
|| Packaging & Delivery
Inner use the plastic wrapping ,out package will use stronger wooden cases.
Our standard package process:
1) Dust & Cleaning
2) Lubricate Drive Parts
3) Divide Machine Into Modules
4) Wrap Modules With Plastic Film
5) Packing Modules into Plywood Cases
6) Mark Shipping Mark In The Cases
If any special requirements, we will pack it as requested.
