|| Product Introduction
Checkweigher with Industrial Metal Detector simplifies inspection processes and keeps your products safe – all in one compact system.Combination Checkweigher and Metal Detector Systems verify product weight and detect metal contaminants in a single, space-saving unit. Built for food production, these systems help you stay compliant, efficient, and confidently in control.
|| Tech Specifications
Model: SG-JS150
Detection hole width: 150mm
Detection hole height: 100-200mm
Detection sensitivity:
H-100mm: Fe≥Φ0.8mm,SUS≥Φ1.2mm
H-120mm: Fe≥Φ0.8mm,SUS≥Φ1.8mm
H-150mm: Fe≥Φ1.2mm,SUS≥Φ2.0mm
H-200mm: Fe≥Φ1.5mm,SUS≥Φ2.5mm
Weighing range: 5-500g
Weighing accuracy: ±0.1g(Depends on products)
Conveyor belt height: 750mm (±50mm)
Conveying capacity: 10Kg/time
Delivery direction: from left to right
Maximum speed of conveyor belt: 25m/min
Conveyor belt material: food grade PU belt
Protection class: IP65
Display and operation mode: LED LCD flat button input
Machine weight: 240kg
Power requirements: AC220V 50HZ
Power: 300W
|| Main Features
1.Dual Inspection in One System
Combines metal detection and dynamic checkweighing for complete quality assurance without added footprint.
2.High-Sensitivity Metal Detection
Detects ferrous, non-ferrous, and stainless steel contaminants across a wide range of products.
3.Compact Design
Ideal for space-constrained production lines or facilities.
4.Auto-Learn & Multi-Product Memory
Speeds up setup and changeovers with intuitive presets and real-time adjustment.
5.USB Data Export
Easily retrieve inspection data in Excel-compatible format for traceability and audits.
6.Durable Stainless Steel Construction
Fabricated from heavy-duty 304 (or optional 316) stainless steel for long-term reliability.
7.Visual and Audible Alarms
Three-tier light tower and sound indicators alert operators to inspection events.
8.Integrated Reject Device
Removes off-spec or contaminated products automatically to minimize rework.
|| Application
Meat & Poultry Processing (packaged cuts, ground meat, sausages, vacuum-sealed and marinated poultry)
Seafood Inspection (fillets, shrimp, frozen fish portions, shellfish blends)
Dairy Products (cheese blocks, yogurt cups, butter, cream-based foods)
Bakery & Snack Foods (cookies, chips, bars, crackers, and baked goods)
Prepared & Frozen Meals (microwaveable trays, vacuum-packed entrees, ready-to-eat kits)
Confectionery & Chocolate (wrapped candies, truffles, molded chocolates)
Automated Packaging Lines (form-fill-seal,and tray-pack conveyors)
|| Our Company
|| Our Customers
|| Our Exhibitions
|| Package & Shipping
1.Before packaged, the machines will be tested strictly to guarantee the stability and high accuracy.
2.After tested, the machines will be wrapped with plastic sheet and carefully packed in wooden cases.
Packing Detail:
1.Each Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
2.We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers and ship them abroad.
