■ Product Introduction
The Industrial Food Conveyor Metal Detector is an advanced inspection system designed for detecting and rejecting metallic contaminants in packaged and unpackaged food products.Metal Detector with Auto Rejection provides reliable metal detection performance while maintaining high throughput efficiency, making it ideal for food processing lines such as snacks, meat, seafood, bakery, dried fruits, and confectionery.
■ Tech Specifications
Type:SG-M400
Detection sensitivity: in empty state
H-100mm: Fe≥Φ0.8mm, Non-Fe≥Φ1.5mm, SUS≥Φ1.5mm
H-120mm: Fe≥Φ0.8mm, Non-Fe≥Φ1.5mm, SUS≥Φ2.0mm
H-150mm: Fe≥Φ1.0mm, Non-Fe≥Φ1.5mm, SUS≥Φ2.0mm
H-200mm: Fe≥Φ1.2mm, Non-Fe≥Φ2.0mm, SUS≥Φ2.5mm
Effective detection hole width: 150-1000mm customized according to requirements
Effective detection hole height: 80-500mm customized according to requirements
Maximum speed of conveyor belt: 25m/min
Conveyor belt material: food grade PU belt
Protection class: IP65
Display and operation mode: LED fast key input/Touchscreen
Machine weight: about 120kg
Power requirements: AC220V 50HZ
Power: 200W
■ Main Features
1.High Sensitivity Detection
Capable of detecting ferrous, non-ferrous, and stainless-steel contaminants with precision.
2.Touch Screen Operation
User-friendly interface for quick parameter setup and product learning.
3.Automatic Rejection System
Options include air-blast, flap, or push-arm rejection depending on product size and weight.
4.Food-Grade Design
Constructed from SUS304 stainless steel with a waterproof and easy-to-clean structure.
5.Conveyor Integration
Smooth, adjustable-speed conveyor ensures consistent product flow and detection accuracy.
■ Application
Bakery and confectionery
Meat, poultry, and seafood processing
Dried fruits, nuts, and snack foods
Frozen foods and ready-to-eat meals
Powder or granular food products
■ Customers
■ Exhibitions
■ Packaging & Delivery
Our machines is fully tested and calibrated before delivery.
It is packed in a strong wooden case with internal shockproof protection.
Various shipping options are available — by sea, air, or land — ensuring safe and on-time delivery by professional logistics partners.
