■ Product Overview
The Pharma Capsule Metal Detector is a high-sensitivity inspection system specifically designed for capsule and tablet production lines.Inline Tablet Metal Detector ensures reliable detection and rejection of ferrous, non-ferrous, and stainless steel contaminants during high-speed pharmaceutical manufacturing.
The hygienic stainless steel structure, tool-free disassembly, and validated rejection mechanisms make it suitable for continuous 24/7 operation in cleanroom environments.
■ Tech Specifications
Type:SG-M50
Inlet height: 770-930mm Port size: 76mm
Outlet Height: 770-860mm Port size: 51mm
Effective passing size: W70*H20mm
Maximum production capacity: 500,000 pcs/hour
Sensitivity(adjustable or not):Yes
Detection sensitivity: Fe: 0.3mm, SUS: 0.5mm,Non-Fe:0.5mm
Operation Mode:Touch Screen/LED fast key input
Machine weight: 60kg
Removal method: flip culling
Working voltage: 220V/110V, 50/60HZ
Equipment dimensions: 1115*550 (1280-1400) mm
Note: The above sensitivity is when the test block freely falls through the detection pipeline. The actual detection sensitivity may vary due to different product characteristics or working environments,it should be based on the actual detection sensitivity.
■ Main Features
1.High sensitivity detection for Fe, Non-Fe, and SUS contaminants.
2.Designed specifically for capsules and tablets.
3.Compatible with capsule filling & polishing machines.
4.GMP / FDA compliant pharmaceutical-grade design.
5.Low product effect with advanced DSP technology.
6.Automatic learning and self-calibration.
7.Compact footprint for easy line integration.
8.Reliable reject system with audit trail support.
9.Stainless steel housing for cleanroom use.
■ Application
Hard gelatin capsules
HPMC capsules
Soft capsules
Tablets and pills
Pharmaceutical granules (capsule feeding stage)
■ Customers
■ Exhibitions
■ Packaging & Delivery
Inner use the plastic wrapping ,out package will use stronger wooden cases.
Our standard package process:
1) Dust & Cleaning
2) Lubricate Drive Parts
3) Divide Machine Into Modules
4) Wrap Modules With Plastic Film
5) Packing Modules into Plywood Cases
6) Mark Shipping Mark In The Cases
If any special requirements, we will pack it as requested.
