Product Overview
Equipped with a high speed/high accuracy force balance load cell.High-end Checkweigher Systems is a kind of high-precision online checkweighing equipment, which can be integrated into various packaging line terminals and conveying systems.Perfect for products such as precision machined parts and applications in food & beverage.
Checkweigher Systems
Product Parameter
Type:SG-300
Weighing Range:5-3000g
Limited of product:L: 350 W:300 H:3mm or more
Accuracy:±0.3g-0.5g Depends on product
Division Scale:0.1g
Belt Speed:0- 60m/min
Max Speed:80 pcs/min
Belt Width:300mm
Machine Weight:100kg
Power Supply:AC-220V 50HZ
Power:200W
Main Material:SUS304 stainless steel
Standard Features
1. Weighing data can be saved to a USB flash disk. All the data can be exported in Excel format and stored up to one year.
2. High rigid load cell guarantees the high speed and high accuracy weighing.
3. The conveyor belt is fully compliant and meets food hygiene law.
4. Easily connect with another device such as metal detector,multi lane packaging machine etc.
5. Wind shield available for the weighing part.
Scope of Application
Company Profile
Customer Visit
Exhibition
Packaging&Shipping
1.Before packaged, the machines will be tested strictly to guarantee the stability and high accuracy.
2.After tested, the machines will be wrapped with plastic sheet and carefully packed in wooden cases.
Packing Detail:
1.Each Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
2.We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers and ship them abroad.
Tag:High Accuracy Inline Check Weigher,Checkweigher Systems
