|| Product Introduction
A Dynamic Tablet Sampling Checkweigher is a high-precision electronic balance specifically designed for accurately weighing a random number of tablets from a batch during the pharmaceutical production process to assess the weight uniformity of the entire batch.
This typically refers to a precision device used for offline, random sampling in laboratories or on-site workshops, rather than a high-speed in-line checkweigher on a production line.
|| Tech Specifications
1.It can detect all types of capsules such as 000#, 00#, 0#, 1#, 2#, 3#, 4#, 5#, SA, SB, and conventional tablets.
2.Weighing range：0-2000mg.Output:up to 60 pcs / min.Highest accuracy:±1mg(Depend on products)
3.Power supply：220V，50HZ.
4.7-inch resistive touch screen .
5.One-touch automatic calibration function, built-in E-grade stainless steel weights.
6.Support communication interfaces RS-232, RS485, Mudbus-TCP communication protocols, USB and Ethernet
7.Automatic cleaning at startup, manual zeroing, data clearing.
8.Sensor overload protection, AD separation mode.
9.The material contact part is stainless steel, or hardened anti-corrosion treatment, which will not cause drug contamination.
10.Sudden power failure self-protection to prevent data loss.
11.Counting function, timely understanding of the weighing quantity.
12.Support power supply voltage customization to meet foreign power supply.
13.One-touch automatic zeroing function, zero point tracking.
|| Main Features
1.High-precision weighing
Equipped with a high-precision weighing sensor, it can accurately measure the weight of a single capsule with an accuracy of up to milligram level.
2. Multi-specification weighing
Capsule sampling weighing machine can carry out sampling weighing of capsules or tablets of different specifications after sorting.
3. Permission management
Three-level permission management of the device interface operating system, setting different permissions for different personnel.
4.Automated operation
It can automatically complete the processes of capsule feeding, weighing, sorting and rejecting unqualified products, reducing manual operations and improving production efficiency.
5. Fast detection
With a faster detection speed, it can adapt to high-efficiency production lines to ensure that it does not affect the overall production process.
6. Sorting function
According to the preset weight standard, the equipment can automatically sort out unqualified capsules (overweight or underweight) from qualified products.
7. Data recording and traceability
Able to record weighing data for easy product quality traceability and statistical analysis.
|| Application
|| Our Customers
|| Our Exhibitions
|| Package & Shipping
1.Before packaged, the machines will be tested strictly to guarantee the stability and high accuracy.
2.After tested, the machines will be wrapped with plastic sheet and carefully packed in wooden cases.
Packing Detail:
1.Each Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
2.We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers and ship them abroad.
