■ Product Overview
The Vertical Powder Granule Metal Detector is a high-sensitivity metal foreign object detection device specifically designed for online detection of powdered materials. The entire machine adopts a vertical gravity-fall structure, suitable for free-fall material processes such as milk powder, coffee powder, starch, food additives, and raw material powders, effectively identifying ferrous, non-ferrous, and stainless steel contaminants. The Food High-sensitivity Free-fall Metal Inspection System can be seamlessly integrated with vertical packaging machines, rotary feeding systems, hoppers, and other production line equipment to ensure that powdered products meet stringent metal foreign object control standards before packaging.
■ Tech Specifications
Name:Gravity-Fed Metal Detector
Detection sensitivity: Fe: 0.4mm, stainless steel: 0.6mm
Material of Construction: 304 Brushed stainless steel
Product:Pre-packaged, free-flowing products
Parameter Adjustment:Auto or manual programming
Alarm Model:Auto rejection diversion flap
Machine Weight:60kg
IP Rating:65
■ Main Features
1. High-sensitivity detection: Accurately identifies ferrous, non-ferrous, and stainless steel foreign objects.
2. Gravity-fall detection: Suitable for free-fall powder processes, high-speed and non-clogging.
3. Rapid pneumatic rejection: Millisecond-level rejection of metal-containing materials, ensuring clean removal.
4. Automatic calibration and anti-interference: Maintains stable detection performance in dusty environments.
5. Food-grade quick-cleaning design: The feed channel can be quickly disassembled for easy cleaning.
6. User-friendly interface: Touchscreen or button operation, real-time data recording and tracking.
7. Supports equipment integration: Seamlessly integrates with vertical packaging machines and feeding systems.
8. Intelligent alarm system: Metal alarm, material blockage alarm, and rejection failure reminder.
■ Application
■ Customers
■ Exhibitions
■ Packaging & Delivery
Our machines is fully tested and calibrated before delivery.
It is packed in a strong wooden case with internal shockproof protection.
Various shipping options are available — by sea, air, or land — ensuring safe and on-time delivery by professional logistics partners.
