|| Product Introduction
The Capsule Checkweigher for Pharma consists of 10 (customizable) weighing channels, which can check weigh capsules of various sizes without changing the mold. Unqualified capsules are automatically rejected to avoid overweight and underweight.
Automatic Tablet Weighing Inspection Systems
|| Tech Specifications
Type：SG-JN10/SG-JN20/SG-JN3O
Weighing scope :5-2000mg
Display scale：0.1mg
Highest sorting accuracy:±0.5mg
Product specification:Capsule-00#-5#/Wafer-Φ5.5-Φ18mm/Thickness-3-12mm/Pill-Φ5.5-Φ12mm(Other sizes or shapes subject to testing)
Highest sorting ability :75000 PCS/HR/150000 PCS/HR/230000 PCS/HR
Number of columns:10 Columns/20 Columns/30 Columns
Power supply:AC-220V±10%, 50HZ
Compressed air:0.3-0.9Mpa
Use environment:15~30°C (The temperature change during use should not exceed the range of 1°C/h.Humidity:30-70%(but no condensation)
Weight of Machine :350kg/500kg/700kg
Shell material:SUS304
You can select the best suitable model depending on the production volume.
|| Main Features
◎Touch screen interface, easy to operate.
◎Default Chinese and English operation interface.
◎Applicable to conventional capsules and tablets.
◎Can actually display the relevant data of each channel.
◎Three-level operation authority management, support self-set password.
◎100 product formula preset storage.
◎All channels can be cleaned without disassembly.
◎Multi-channel product passing improves production efficiency (customizable number of channels).
◎Capsules placed in the feed hopper are divided into multiple channels by the silo and transported, weighed and sorted at high speed.
◎Improve the reliability and environmental flexibility of capsule processing.
|| Application
|| Our Company
|| Our Customers
|| Our Exhibitions
|| Package & Shipping
1.Before packaged, the machines will be tested strictly to guarantee the stability and high accuracy.
2.After tested, the machines will be wrapped with plastic sheet and carefully packed in wooden cases.
Packing Detail:
1.Each Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
2.We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers and ship them abroad.
